| 硬件规格 |
| 国际标准 |
IEEE 802.3 10Base-T
IEEE 802.3u 100Base-TX and 100Base-FX |
| 电口 |
1 x 10/100Base-TX port, Auto-negotiation,
Auto-MDI-MDI-X
|
| 光纤端口 |
1 x 100Base-FX |
| 光纤距离 |
FST-801 : ST / Multi-mode / 2km
FST-802 : SC / Multi-mode / 2km
FST-802S15 : SC / Single Mode / 15km
FST-802S35 : SC / Single Mode / 35km
FST-802S50 : SC / Single Mode / 50km
FST-806A20: WDM SC / Single Mode / 20km
FST-806B20: WDM SC / Single Mode / 20km |
| 波长 |
FST-801: 1310nm
FST-802: 1310nm
FST-802S15: 1310nm
FST-802S35: 1310nm
FST-802S50: 1310nm
FST-806A20: TX: 1310nm, RX: 1550nm
FST-806B20: TX: 1550nm, RX: 1310nm |
| 最大发射功率（dBm） |
FST-801: -14
FST-802: -14
FST-802S15:0
FST-802S35:-8
FST-802S50:0
FST-806A20:-8
FST-806B20:-8
|
| 最小发射功率（dBm） |
FST-801: -20 (62.5/125�m), -23.5 (50/125�m)
FST-802: -20 (62.5/125�m), -23.5 (50/125�m)
FST-802S15: ?20
FST-802S35: -15
FST-802S50:-5
FST-806A20:-14
FST-806B20:-14 |
| 接收灵敏度（dBm） |
FST-801: -31.8
FST-802: -31.8
FST-802S15: -32
FST-802S35:-34
FST-802S50: -35
FST-806A20:-31
FST-806B20:-31 |
| 最大输入功率（dBm） |
FST-801: -14
FST-802: -14
FST-802S15:0
FST-802S35:0
FST-802S50:0
FST-806A20:0
FST-806B20:0 |
| 速率 |
Ethernet: 10/20Mbps for Half / Full-duplex
Fast Ethernet: 100/200Mbps for Half / Full-duplex |
| 最大转发数据包大小 |
1600Bytes |
| DIP 开关 |
DIP-1: Fiber Full / Half duplex modes select
DIP-2: Copper Forced Mode / Auto-negotiation Mode
DIP-3: Copper Speed 10Mbps / 100Mbps
DIP-4: Copper Full / Half duplex modes select
DIP-5: Fiber LLR (Link Loss Return) Enable / Disable
DIP-6: Fiber LLCF(Link Loss Carry Forward) Enable / Disable |
| LED 指示灯 |
System: PWR
TP: LNK/ ACT, FDX/ COL, 100
FX: LNK/ ACT, FDX/ COL |
| 电源输入 |
DC 5V, 2A |
| 功率消耗 |
6.2 Watts/ 21 BTU (maximum) |
| 尺寸 (W x D x H) |
94 x 81 x 26 mm |
| 重量 |
0.22kg |
| 布线 |
10Base-T: 2-pair Cat. 3, 4, 5 UTP cable, up to 100 meters
100Base-TX: 2-pair Cat. 5 UTP cable, up to 100 meters
100Base-FX:
-50/ 125?gm or 62.5/ 125?gm multi-mode fiber cable, up to 2km.
- 9/ 125?gm single-mode cable, provides long distance for 15/ 20/ 35/ 50km |
| 操作环境 |
0~50 Degree C, 5~90% RH |
| 储存环境 |
-10~70 Degree C, 5~90% RH |
| 认证 |
FCC Class B, CE mark |
