| 硬件规格 |
| 国际标准 |
IEEE 802.3, 10Base-T
IEEE 802.3u, 100Base-TX, 100Base-FX
IEEE 802.3x, Flow Control
IEEE 802.1p, Class of Service |
| 电口 |
1 x 10/100Base-TX RJ-45 port
Auto-negotiation, Auto-MDI/MDI-x |
| 光纤端口 |
1 x 100Base-FX |
| 光纤距离 |
FT-902 : SC / Multi-mode / 2km
FT-902S15 : SC / Single Mode / 15km
FT-902S35 : SC / Single Mode / 35km
FT-902S50 : SC / Single Mode / 50km
FT-905A : SFP / Vary on transceiver module
FT-906A20: WDM SC / Single Mode / 20km
FT-906B20: WDM SC / Single Mode / 20km
|
| 波长 |
FT-902: 1310nm
FT-902S15: 1310nm
FT-902S35: 1310nm
FT-902S50: 1310nm
FT-905A: Vary on transceiver module
FT-906A20: TX: 1310nm, RX: 1550nm
FT-906B20: TX: 1550nm, RX: 1310nm
|
| 最大发射功率（dBm） |
FT-902: -14
FT-902S15:0
FT-902S35:-8
FT-902S50:0
FT-905A:NA
FT-906A20:-8
FT-906B20:-8 |
| 最小发射功率（dBm） |
FT-902: -20 (62.5/125�m), -23.5 (50/125�m)
FT-902S15: -20
FT-902S35: -15
FT-902S50:-5
FT-905A:NA
FT-906A20:-14
FT-906B20:-14 |
| 接收灵敏度（dBm） |
FT-902: -31.8
FT-902S15: -32
FT-902S35:-34
FT-902S50: -35
FT-905A:NA
FT-906A20:-31
FT-906B20:-31 |
| 最大输入功率（dBm） |
FT-902: -14
FT-902S15:0
FT-902S35:0
FT-902S50:0
FT-905A: NA
FT-906A20:0
FT-906B20:0 |
| 双绞线 |
10/20Mbps for Half/Full-Duplex
100/200Mbps for Half/Full-Duplex |
| 高速光纤 |
200Mbps for Full-Duplex |
| 电缆双绞线 |
10Base-T: 2-pair UTP Cat. 3, 4, 5, up to 100 m
100Base-TX: 2-pair UTP Cat. 5, up to 100 m |
| 光纤电缆 |
� 50/125�m or 62.5/125�m multi-mode fiber cable, up to 2km.
� 9/125�m single-mode cable, provides long distance for
?15/20/35/50km or longer (very on SFP module) |
| LED 指示灯 |
PWR,
TP LINK/ACT, TP FDX, TP SPEED
Fiber LINK/ACT, Fiber FDX |
| 功率消耗 |
5.5 Watts (maximum) |
| 电源输入 |
5V/2A |
| 尺寸 (W x D x H) |
93 x 69 x 25 mm |
| 操作环境 |
Operating temperature: 0 to 50 degrees C
Humidity: 10~90% non-condensing |
| 储存环境 |
Storage temperature: -25 to 70 degrees C
Humidity: 10~90% non-condensing |
| 认证 |
FCC Class A, CE Class B |
