| Standards |
IEEE 802.3u, 10/100Base-TX and 100Base-FX |
| TP Connector |
RJ-45 port (Auto-MDI/MDI-X) Twisted Pair, EIA568 |
| Fiber Connector |
SMI POF port (multi-mode), 650nm wavelength |
| Data Rate |
10/100Mbps (TP); Auto-Negotiation for duplex mode
100Mbps (FX); full-duplex mode |
| TP Cable |
4 pair Cat. 3 or 5 UTP, up to 100m |
| Fiber Cable |
IEEE 1394b SMI Patch cord (0.98mm /1mm), up to 50m |
| LED Indicators |
PWR, TP. POF |
| Dimensions (W x D x H) |
86 x 62 x 23 mm
|
| Power Requirements |
5V DC, 2A |
| Temperature |
Operating: 0~50 degrees C
Storage: -40~70 degrees C |
| Humidity |
Operating: 10~90%
Storage: 10~90% (non-condensing) |
| Regulation Compliance |
FCC Part 15 Class A, CE |
