硬件特性 |
电口 |
Ports
4 x 10/100Base-TX, auto negotiation, auto-MDI / MDI-X
Cable
10Base-T : 2-pair UTP Cat. 3, 4, 5 cable (100meters, max.)
100Base-TX : 2-pair UTP Cat. 5 cable (100meters, max.) |
光口 |
Port
1 x 100Base-FX
Cable
ISW-511T: 50/125?m / 62.5/125?m fiber
ISW-511TS15: 9/125?m fiber
Mode
ISW-511T: Multi-mode
ISW-511TS15: Single-mode
Distance
ISW-511T: 2km
ISW-511TS15: 15km
Frequency
ISW-511T: 1310nm
ISW-511TS15: 1310nm
Launch Power
ISW-511T: Max. -14dBm, Min. -20dBm
ISW-511TS15: Max. 0dBm, Min. -20dBm
Receive Sensitivity
ISW-511T: -32dBm
ISW-511TS15: -32dBm
Max. Input Power
ISW-511T: -14dBm
ISW-511TS15: 0dBm |
尺寸 |
135 x 97 x 32 mm |
重量 |
436g |
电源要求 |
12~48V DC
Redundant power with polarity reverse protection function
|
功率/损耗 |
13.7 watts / 46 BTU |
安装方式 |
DIN rail kit and wall mount ear |
报警功能 |
Provides one relay output for power failure
Alarm relay current carry ability: 1A @ DC 24V
|
2层特性 |
处理方式 |
Store-and-Forward |
MAC地址表 |
2K entries |
缓存 |
1Mbit |
流量控制 |
Back pressure for half duplex,
IEEE 802.3x pause frame for full duplex
|
背板带宽 |
1Gbps |
吞吐量 |
0.74Mpps @ 64Bytes
|
标准一致性 |
标准一致性 |
IEEE 802.3 Ethernet, 10Base-T
IEEE 802.3u Fast Ethernet, 100Base-TX, 100Base-FX
IEEE 802.3x full-duplex flow control
|
温度 |
Operating: -40~75 degrees C
Storage: -40~85 degrees C
|
湿度 |
Operating: 5~90%
Storage: 5~90% (Non-condensing) |
遵从法规 |
FCC Part 15 Class A, CE |
Stability Testing |
IEC60068-2-32 (Free fall)
IEC60068-2-27 (Shock)
IEC60068-2-6 (Vibration)
|
