产品 |
端口 |
WAN
1 x 100Base-FX port
LAN
4 x 10/100Base-TX port
|
光纤接口 |
Connector
FRT-401: SC
FRT-401S15: SC
FRT-405: SFP
Mode
FRT-401: Multi-mode
FRT-401S15: Single-mode
FRT-405: Vary on module
Distance
FRT-401: 2km
FRT-401S15: 15km
FRT-405: Varies on module
|
光学波长 |
FRT-401: 850nm
FRT-401S15: 1310nm
|
发射功率(dBm) |
Max.
FRT-401: -14
FRT-401S15: -7
Min.
FRT-401: -19.0
FRT-401S15: -20
|
接收灵敏度 |
FRT-401: -34.5
FRT-401S15: -28
|
最大输入功率 |
FRT-401: -14
FRT-401S15: -8
|
光纤电缆 |
� 50/125?m or 62.5/125?m multi-mode fiber cable, up to 2km.
� 9/125?m single-mode cable, provide long distance for 15/20/35/50km or longer (varies on SFP module)
|
LED 指示灯 |
PWR, Fiber, LAN1-4 |
按钮 |
1 x reset button |
软件 |
最大会话 |
4096 |
协议/特性 |
Router and Bridge mode
Static Routing and RIPv1/2
DMZ and Virtual Server
802.1D
802.1Q VLAN support
QoS
SNTP
DHCP Server / Client
IGMP Proxy and DNS Proxy
Universal Plug and Play (UPnP) Compliant
DDNS (Dynamic Domain Name System)
|
VPN |
VPN Pass-through |
安全 |
Built-in NAT Firewall
MAC / IP/ Port Filtering
Content Filtering
SPI Firewall support
Password protection for system management
|
管理 |
Web-Based configuration
Available Syslog support
TR-069*
SNMP v1/v2c
TS-1000 and 802.3ah OAM support
|
环境技术指标 |
尺寸(W x D x H) |
186 x 143 x 35mm |
电源 |
12V DC, 1A |
温度/湿度 |
Operating: 0~50 degrees C, 5~90% (non-condensing)
Storage: -10~70 degrees C, 0~95% (non-condensing)
|
认证 |
FCC, CE |
* Features enhancement by future firmware upgradeable. |
