| Video Specifications |
| Image Sensor |
2 mega-pixel CMOS image sensor |
| Lens |
2.7-9mm vari-focal lens with ICR and DC iris |
| Sensitivity |
0.5 lux |
| View Angle |
H: 30.4~101 degrees / V: 23~75 degrees |
| IR LED |
High light IR LED x 18pcs |
| IR Wavelength |
850 nm |
| IR Distance |
20M |
| Video Encoder |
H.264 / MPEG-4 / M-JPEG |
| Rate Control |
CBR (Constant Bit Rate) / VBR (Variable Bit Rate) |
| Video Resolution |
H.264 UXGA / 720p / SXGA/ VGA / QVGA / QCIF
M-JPEG UXGA / 720p / SXGA/ VGA / QVGA
MPEG4 QCIF (Only for 3GPP)
|
| Frame Rate |
UXGA Up to 15fps
SXGA Up to 22fps
HD-720p / SVGA / VGA / QVGA / QCIF Up to 30fps
|
| Image Control |
Brightness, sharpness, contrast, AGC, BLC, night mode
text, time and date overlay
|
| Audio Specifications |
| Audio Codec |
G.711 / AMR |
| Audio I/O |
Audio in: external microphone
Audio out: external speaker
|
| Audio Streaming |
One-way or two-way |
| Audio Output |
Phone jack |
| Network and Configuration |
| Network Interface |
1 x RJ-45 |
| Network Standard |
IEEE 802.3 / IEEE 802.3u / IEEE 802.3af |
| Network Protocol |
TCP, UDP, HTTP, SMTP, FTP, NTP, DNS, DDNS,
DHCP, UPnP, RTSP, RTP, RTCP, PPPoE, 3GPP, ICMP
|
| Browser / Software |
Microsoft Internet Explorer 6.0 or later
PLANET Cam Viewer 3 Lite/Pro
|
| Motion Detection |
3 areas definable |
| Environment Specifications |
| Protection Class |
IP-66 classification with vandalproof and weatherproof features |
| Power Requirements |
12V DC, 1A
IEEE 802.3af Power over Ethernet
|
| Dimensions (W x D x H) |
126 x 100 x 126 mm |
| Weight |
835 g |
| Power Consumption |
500mA max (IR LED on) |
| Operating Temperature |
-20 ~ 50 degrees C |
| Operating Humidity |
20 ~ 80% (non-condensing) |
| Emission |
CE, FCC |
