| 硬件 |
| WAN |
| 接口 |
1 x RJ-45 |
| SHDSL |
ITU-T G.991.2 (Annex AF, Annex BG, Annex ABFG)
ITUT G.991.2 rev2 (.bis) |
| 编码体系 |
TCPAM-16, TCPAM-32 |
| EFM 结合 |
IEEE 802.3ah PAF |
| 数据速率 |
N x 64Kbps (N=3~89) |
| 阻抗 |
135ohms |
| LAN |
| 接口 |
1 x RJ-45 |
| 网络接口 |
10Base-T, 100Base-TX |
| 数据速率 |
10/100Mbps, full/half-duplex |
| Console 端口 |
| 接口 |
RS-232 |
| LED 指示灯 |
| 常规 |
PWR, ALM |
| WAN |
LNK, ACT |
| LAN |
LNK/ACT |
| 软件 |
| 路由 |
IP Routing
Static Routing and RIPv1/RIPv2
IP masquerading NAT
DHCP server
DNS relay and caching
Natural NAT firewall
IP precedence (RFC 791)
|
| 桥接 |
IEEE 802.1D transparent learning bridge |
| 配置 |
Local console (RS-232) , Telnet, Web (HTTP), Password control |
| 网络管理 |
SNMP v1 / SNMP v2 agent
MIB II
|
| ATM |
Up to 8 PVCs
UBR/CBR traffic shaping
AAL5
OAM F5 loopback
ATM Forum UNI 4.0
|
| AAL5 封装 |
VC multiplexing and SNAP/LLC
Ethernet over ATM (RFC 2684/1483)
PPP over ATM (RFC 2364)
Classical IP over ATM (RFC 1577)
|
| PPP |
PPP over Ethernet (RFC 2516)
PPP over ATM (RFC 2364)
User authentication with PAP/CHAP/MS-CHAP
|
| 物理/电气 |
| 尺寸 (W x D x H) |
187 x 145 x 33 mm |
| 电源 |
12V DC, 1.0A |
| 功率消耗 |
7 watts / 23.8 BTU |
| 工作温度 |
0 ~ 45 degrees C |
| 储存温度 |
-20 ~ 70 degrees C |
| 工作湿度 |
0 ~ 95 degrees C (non-condensing) |
| 储存湿度 |
0 ~ 95 degrees C (non-condensing) |
| EMC/EMI |
FCC, CE |
