| Hardware Platform |
| Wi-Fi |
Gain: 1 x 1dBi antenna for Z-Wave |
| LED Indicators |
PWR |
| Buttons |
1 x reset button |
| LAN Interface |
1 x 10/100Mbps Ethernet port |
| Enclosure |
IP30 metal |
| Installation |
Wall mount, magnetic wall mount and DIN-rail kit |
| Network and Configuration |
| Network Standard |
IEEE 802.3 10BASE-T
IEEE 802.3u 100BASE-TX
|
| Z-Wave Frequency |
Europe: 868.42MHz
America: 908.42MHz
|
| HA Functions |
Sense Control
Door Lock Control
Sensor Trigger
Schedule Setting
Supports Mobile Phone Push Notification
Supports Device Location
|
| General |
| Power Requirements |
12V DC, 1A |
| Operating Temperature |
0 ~ 45 degrees C |
| Operating Humidity |
10 ~ 90% (non-condensing) |
| Weight |
441g |
| Dimensions (W x D x H) |
148 x 134 x 25 mm |
| Emission |
CE, FCC |
