| Serial Port |
| 接口 |
RS-232 x 1
RS-422 / RS-485 x 1
|
| 连接器 |
DB9 for RS-232
Terminal block for RS-422 / RS-485
|
| 波特率 |
300bps to 921600bps |
| 速率 |
5, 6, 7, 8 |
| 奇偶校验类型 |
1, 1.5/2 |
| 停止位 |
Odd, Even, None, Space, Mark |
| 流量控制 |
Hardware, None |
| 信号 |
RS-232: DCD, RxD, TxD, GND, RI
RS-422: Tx+, Tx-, Rx+, Rx-
RS-485: Data A (+), Data B (-)
|
| Fast Ethernet Port |
| 连接器 |
ICS-2102 / ICS-2102S15: SC
ICS-2105A: LC (SFP) |
| 型号 |
ICS-2102: Multi-Mode
ICS-2102S15: Single Mode
ICS-2105A: Multi-Mode / Single-Mode (Vary on SFP module) |
| 距离 |
ICS-2102: 2km
ICS-2102S15: 15km
ICS-2105A: 2km up to 120km (Vary on SFP module)
|
| 光波长 |
ICS-2102: 1300nm
ICS-2102S15: 1310nm
ICS-2105A: (Vary on SFP module) |
| 类型 |
ICS-2102: 50/125μm or 62.5/125μm multi-mode fiber cable
ICS-2102S15: 9/125μm single-mode fiber cable
ICS-2105A: 50 or 62.5/125μm multi-mode fiber cable
9/125μm single-mode fiber cable
|
| Hardware |
| LED指示灯 |
System: Power 1, Power 2, Fault
TP or Fiber Port: Link / Active
Serial Port: Serial port mode, RS-232, RS-422 or RS-485
|
| 管理 |
Web Management
PLANET Smart Discovery Utility
|
| Virtual COM Utility Platform Supports |
Windows Base Only:
Windows XP
Windows Server 2003
Windows 7
Windows Server 2008
Windows 8 (Must install latest version of WinPcap)
Windows Server 2012 (Must install latest version of WinPcap)
|
| 工作模式 |
TCP Server
TCP Client
UDP Client
Virtual COM
Telnet Server
Pair Connection – Remote (Slave)
Pair Connection – Local (Master)
|
| 外形尺寸 (W x D x H) |
135 x 97 x 32 mm |
| 重量 |
ICS-2102 / ICS-2102S15 : 431g
ICS-2105A: 428g |
| 电源支持 |
12~48V DC / 24V AC, Redundant power with polarity reverse protection function |
| 电源功耗 |
10.1 watts / 34.44 BTU (max) |
| 安装 |
DIN rail kit and wall mount ear |
| 告警 |
Provides one relay output for power failure
Alarm relay current carry ability: 1A @ DC 24V |
| 附件 |
IP30 metal case |
| 环境 |
Operating Temperature: -10~60 degrees C
Storage Temperature: -20~75 degrees C
Operating Humidity: 10~90% RH
Storage Humidity: 5~90% RH
|
| 标准 |
FCC Class A, CE Certification Class A |
| 标准性 |
IEEE 802.3 10Base-T
IEEE 802.3u 100Base-TX / 100Base-FX
EIA/TIA RS-232/422/485 |
| 安规认证 |
RoHS |
| 稳定性测试 |
IEC60068-2-32 (Free Fall)
IEC60068-2-27 (Shock)
IEC60068-2-6 (Vibration) |
| * Note: Reset Button on the front panel for resetting to factory default |
