Video Specifications |
Image Sensor |
1/2.7" Progressive CMOS |
Lens |
4mm fixed lens with Fixed Iris |
Sensitivity |
0.5 lux @ F1.4 |
Viewing Angle |
H: 66 degrees
V: 52 degrees
|
Video Encoder |
H.264 / MPEG-4 / M-JPEG |
Rate Control |
CBR (Constant Bit Rate) / VBR (Variable Bit Rate) |
Video Resolution |
1920 x 1080 / 1280 x 720 / 640 x 360 / 320 x 180 / 160 x 90 |
Frame Rate |
Up to 30fps for all resolutions (2M Real-time) |
Image Control |
AE, AWB
3D Noise reduction
Color, Brightness, Sharpness, Contrast, Hue
Mirror/Flip
8 Privacy Masks
Text, time and date overlay
|
Audio Specifications |
Audio Codec |
RTSP: G.711 64kbps, G.726 32kbps
3GPP: AMR
|
Audio Streaming |
One-way or two-way |
Microphone (Audio Input) |
External microphone input, phone jack |
Audio Output |
Adjustable audio output gain, phone jack |
Network and Configuration |
Network Interface |
1 x RJ-45 |
Network Standard |
IEEE 802.3 / IEEE 802.3u / IEEE 802.3af |
Network Protocol |
IPv4, TCP, UDP, HTTP, HTTPS, SMTP, FTP, NTP, DNS, DDNS, DHCP, DIPS, ARP, Bonjour, UPnP, RTSP, RTP, RTCP, IGMP, PPPoE, 3GPP, Samba, ICMP |
Browser / Software |
Microsoft Internet Explorer 6.0 or later
PLANET Cam Viewer 3 Lite/Pro
|
Motion Detection |
10 areas definable |
Environment Specifications |
Power Requirements |
12V DC, 1A |
PoE |
IEEE 802.3af (PoE is for IP cam & IR LED only, heater & fan require external adaptor) |
Dimensions (W x D x H) |
141 x 310 x 120 mm |
Weight |
1335 g |
Power Consumption |
Max. 8W for camera and IR LEDs
Max. 5W for heater only
|
Protection Class |
IP-66 classification with weatherproof feature |
Operating Temperature |
-30 ~ 60 degrees C |
Operating Humidity |
0 ~ 95% (non-condensing) |
Emission |
CE, FCC |
