| 硬件规格 |
| RJ45 Port |
8个千兆复用电口, 共享1～8号端口 支持自动协商和MDI / MDI-X自适应 |
| SFP端口 |
24个千兆SFP mini-GBIC 端口 |
| Console端口 |
1 unit |
| Switching method |
Store-and-forward |
| Backplane Bandwidth |
68Gbps |
| Address Table |
8,000 MAC address table with auto-learning and aging mechanism |
| 共享数据缓冲区 |
1392 kilobytes |
| Flow Control |
Supports IEEE 802.3x full-duplex and half-duplex mode |
| Jumbo Frame |
10Kbytes |
| LED指示灯 |
System: Power, Master
Ports: 10/100/1000 Link/Act, SFP Link, Stack Port Link
|
| Reset Button |
< 5 seconds: system restart; > 5 seconds: restore to factory defaults |
| 尺寸 (W x D x H) |
440 x 200 x 44.5 mm, 1U 高度 |
| Weight |
3 KG |
| Power Consumption |
Max. 50 watts / 170.5 BTU |
| Power Requirement |
SGSW-24240
100~240V AC, 50/60Hz
SGSW-24240R
100~240V AC, 50/60Hz
48V DC @ 0.6A, Range: -30 ~ -60V |
| 堆叠 |
| Stacking Port |
2 5Gbps HDMI-like ports |
| Number of Stacked Units |
16 units |
| Stacking Bandwidth |
10Gbps ( 全双工) |
| 堆叠ID显示 |
7-Segment LED显示 (1~9, A~F,0) |
| Stacking Topology |
Ring / Chain / Back-to-Back stack |
| 2层功能 |
| 基本管理界面 |
Console, 远程登录, Web管理, SNMPv1, v2c |
| 安全管理界面 |
SSH, SSL, SNMP v3 |
| Port Configuration |
Port enable/disable; Auto-negotiation 10/100/1000Mbps full-duplex and half-duplex switching; Flow control enable/disable |
| VLAN |
基于802.1Q tagged VLAN， 支持255 VLAN组 Q-in-Q PVE 基于端口的VLAN 支持255个vlan组，最大4096个 vlan ID |
| 生成树协议 |
IEEE 802.1D
IEEE 802.1w
IEEE 802.1s |
| Link aggregation |
IEEE 802.3ad LACP / Static Trunk
最大支持12组，每组16个端口
|
| QoS |
每个端口8个输出队列 基于端口、802.1p、802.1Q、DSCP/TOS的优先级 |
| IGMP Snooping |
IGMP (v1/v2/v3)Snooping
支持IGMP查询模式 |
| 访问控制列表 |
IP- and MAC-based ACL, up to 256 entries |
| SNMP MIBs |
RFC-1213 MIB-II
IF-MIB
RFC-1493 Bridge MIB
RFC-1643 Ethernet MIB
RFC-2863 Interface MIB
RFC-2665 Ether-Like MIB
RFC-2819 RMON MIB
RFC-2737 Entity MIB
RFC-2618 RADIUS Client MIB
RFC-2933 IGMP-STD-MIB
RFC3411 SNMP-Frameworks-MIB
IEEE 802.1X PAE
LLDP
MAU-MIB |
| 标准 |
| Authentication Standard |
FCC Part 15 Class A, CE |
| Security Certification |
UL, cUL |
| 遵循国际标准 |
IEEE 802.3 10Base-T
IEEE 802.3u 100Base-TX / 100Base-FX
IEEE 802.3z Gigabit SX/LX
IEEE 802.3ab Gigabit 1000T
IEEE 802.3x Flow Control and Back pressure
IEEE 802.3ad Port trunk with LACP
IEEE 802.1D Spanning tree protocol
IEEE 802.1w Rapid spanning tree protocol
IEEE 802.1s Multiple spanning tree protocol
IEEE 802.1p Class of service
IEEE 802.1Q VLAN Tagging
IEEE 802.1x Port Authentication Network Control
IEEE 802.1ab LLDP
RFC 768 UDP
RFC 793 TFTP
RFC 791 IP
RFC 792 ICMP
RFC 2068 HTTP
RFC 1112 IGMP version 1
RFC 2236 IGMP version 2 |
| 环境 |
| Operating Environment |
Temperature: 0~50°C; Relative humidity: 20~95% (non-condensing) |
| Storage Environment |
Temperature: 0~50°C; Relative humidity: 20~95% (non-condensing) |
