| Video Specifications |
| Image Sensor |
1/2.7" progressive CMOS |
| Lens |
4 mm, F1.5 |
| Minimum illumination |
0.2 Lux @ F1.2 |
| View Angle (Horizontal / Vertical) |
66 / 52 degrees |
| Scan Method |
Progressive |
| Video Encoder |
H.264 / M-JPEG |
| Rate Control |
VBR (Variable Bit Rate) |
| Video Resolution |
H.264 1080P / 720P
M-JPEG 1080P / 720P / D1 / CIF
|
| Frame Rate |
15fps for 1080p
30fps for other resolutions
|
| Image Control |
AWB, AES |
| Audio Specification |
| Audio Codec |
G.711, G.726 |
| Audio In |
Internal Microphone |
| Network and Configuration |
| Network Interface |
1 x RJ-45 |
| Network Standard |
IEEE 802.3 / IEEE 802.3u |
| Network Protocol |
TCP/IP, UDP, RTP, RTSP, HTTP, ICMP, FTP, SMTP, DHCP, IGMP |
| Browser / Software |
Microsoft Internet Explorer 6.0 or later, Cam Viewer 3 Lite/Pro |
| Motion Detection |
10 area definable |
| Environment Specifications |
| Power Requirement |
IEEE 802.3af |
| Dimension (? x H) |
110 x 50 mm |
| Weight |
180g |
| Power Consumption |
3.8W max. |
| Operating Temperature |
0 ~ 50 degrees C |
| Operating Humidity |
10 ~ 90% (non-condensing) |
| Emission |
CE, FCC |
